Hyundai
Hyundai Genuine 39180-2B000 Crankshaft Position Sensor
Hyundai Genuine 39180-2B000 Crankshaft Position Sensor
✔ Genuine Hyundai 39180-2B000 Crankshaft Position Sensor — OEM Part
✔ Fitment: Select Hyundai (Accent, Elantra, Kona, Tucson, Veloster) and Kia (Forte, Rio, Soul, Seltos) models (2010–2021)
✔ Direct replacement for factory crankshaft position sensor — no modifications required
✔ Manufactured to Hyundai’s original specifications
✔ Inductive Sensor design — 2-pin connector with 900 Ohm resistance
✔ Genuine Hyundai quality — ensures accurate engine timing and reliable starting
Genuine Hyundai 39180-2B000 Crankshaft Position Sensor
Engine stalling, rough idling, difficulty starting, or a check engine light with crankshaft position codes (P0335–P0339) — these are common signs that your crankshaft position sensor is failing . The sensor monitors the rotation of the crankshaft and sends this data to the engine control unit (ECU). The ECU uses this information to calculate ignition timing and fuel injection for proper engine operation . A faulty sensor can cause the engine to stall, fail to start, or run poorly. Replacing it with this genuine Hyundai part restores accurate engine timing and reliable performance.
This is a factory-original Hyundai crankshaft position sensor (OE part number 39180-2B000). It features an inductive sensor design with a 2-pin oval connector, 900 Ohm resistance, and a 280 mm cable length . The sensor is designed for direct installation and includes the necessary mounting provision. This is the same part sold at Hyundai and Kia dealerships.
When to Replace
When to Replace
Product Details & Highlights
Product Details & Highlights
Package Contents
Package Contents
FAQ
FAQ
Hyundai Genuine 39180-2B000 Crankshaft Position Sensor
OEM Part Numbers
• 39180-2B000
• 39180-2B100 (Cross-reference)
Cross Reference / Analogs
| Brand | Part Number |
|---|---|
| KIA | 39180-2B000 |
| KIA / HYUNDAI | 39180-2B100 |
| BOSCH | 0 986 280 497 |
| BLUE PRINT | ADG07272 |
| DELPHI | SS11307 |
| VALEO | 366133 |
| HELLA | 6PU 009 163-471 |
| MEYLE | 37-14 810 0001 |
| METZGER | 0902267 |
| METZGER | 0902355 |
| MEAT & DORIA | 87679 |
| HOFFER | 7517679 |
| ERA | 550575 |
| ERA | 550575A |
| FACET | 9.0571 |
| FAE | 79334 |
| BREMI | 60214 |
| MOBILETRON | CS-K025 |
| LUCAS | SEB2049 |
| NTY | ECP-KA-006 |
| VEMO | V52-72-0105-1 |
| TOPRAN | 820 600 |
| MAGNETI MARELLI | 064848204010 |
| ESEN SKV | 17SKV540 |
| ABAKUS | 120-04-061 |
| JAPANPARTS | SAM-H04 |
| KAVO PARTS | ECR-3006 |
| AUTLOG | AS4670 |
| TRISCAN | 8855 43111 |
| WAI | CRK9302 |
| QUINTON HAZELL | XREV637 |
| STELLOX | 06-00075-SX |
| CARQUEST | 71-5610 |
| WELLS | SU13885 |
| AIRTEX | 5S12470 |
Vehicle Fitment Table (OEM Compatibility)
Important Fitment Notes:
• Always verify by VIN – Fitment is determined by the specific engine code and model year. Confirm your application before ordering.
• Inductive sensor design – This sensor uses a magnet and coil to detect the position of the crankshaft teeth, generating an AC waveform signal .
• 2-pin oval connector – Verify the connector matches your vehicle's harness .
• Genuine Hyundai quality – This is an OEM part, not an aftermarket or Chinese replica.
Condition
New (100% genuine Hyundai packaging)
Product Type
Crankshaft Position Sensor (CKP Sensor / RPM Sensor)
Function
The crankshaft position sensor monitors the rotational position and speed of the crankshaft. It sends this data to the ECU, which calculates ignition timing and fuel injection for proper engine operation . If the signal is lost, the ECU may cut spark and fuel to protect the engine .
Applications
This sensor fits a wide range of Hyundai and Kia models from approximately 2010 through 2021, including Accent, Elantra, Kona, Tucson, Veloster, Forte, Rio, Seltos, and Soul.
Important: This sensor is designed for specific Hyundai and Kia applications. If in doubt, send us your VIN before ordering.
Technical Specifications
Warranty
Hyundai's original manufacturer warranty applies. For claims, please contact your nearest Hyundai authorized dealer with your proof of purchase. Warranty terms may vary by region — contact us before purchase if you need a warranty confirmation.
